# Spoke calculator. Length's calculation of the spokes for all bicycles

Designed for self-calculation of a J-form spoke of any thickness. You can count on electric bicycles for motor hubs, for hubs with internal shifting, for the front or rear wheels, and generally for any wheels with spokes. All dimensions except the number of holes are indicated in mm. Parameter descriptions are at the bottom of the page.
Rim settings
Hub settings
Lacing options
Rim settings
Number of spokes.
The spokes holes number of the rim is shown here. The number of holes must match the number of holes in the hub.
Internal diameter of the rim.
It is measured from one edge to another by eyelets (if any). The most accurate measurement will be if you measure cross to cross in two places and calculate the average value, since the rims, even new ones, are deformed and always a little oval in shape. If you know the ERD of the rim, then you can subtract 2 mm from it, enter the value in the "internal diameter of the rim" and put 1 mm in the "rim thickness". We draw your attention !!! According to our measurements, since 2015, the wrong ERD is indicated on the rims of Mach1. Faithful will be 2 mm larger.
Rim thickness.
Measured by eyelet (if any) using a depth bar on a vernier caliper and a flat head screwdriver. You need to insert the depth bar into the hole for the spoke from the side of the hub, extend a little more than the height of the eyelet. Push the depth bar fully into the eyelet (rim) with a flat screwdriver. For accuracy, add 0.2-0.4 mm.
Hole spacing of the rim.
For measurement, the rim is placed on a flat surface. The vernier calipers depth bar measures the upper edge of the upper spoke hole (h1) and the upper edge of the lower hole (h2). Using the formula h1 - h2 we get the desired value.
Displacement of rim holes.
For measurement, the rim is placed on a flat surface. The caliper depth bar measures the upper edge of the upper spoke hole (h1) and the lower edge of the lower hole (h2). Next, use a vernier caliper to measure the width of the rim profile (w).
Using the formula |(w - h1 - h2)|/2 we get the desired value.
Hub settings
Flange offset.
This is the distance from the installation location to the center (in thickness) of the flange. It is possible to measure with both a depth bar and a regular angle, while removing the nuts/QR.
Flange diameter.
The distance is measured at the centers of the opposite holes on the same flange.
Spoke hole diameter.
Often, even with the same hub manufacturer, the diameter of the hole varies greatly, although both hubs will be designed for the same spoke. Such a difference can affect the final choice of spokes, as the resulting values of the length of the spokes will be rounded up or down. For an accurate calculation, you need to measure at least 3 holes and calculate the average value.
Overlocknut distance.
Landing distance of the hub. Measured by a caliper.
Lacing options
